Antenna Magus是全球第一款天线快速设计与天线知识管理工具。

Antenna Magus集成了标准天线设计、阵列设计、转换器设计以及天线设计知识管理等功能,包括:1、完整的天线设计流程;2、天线阵列综合设计工具;3、波导转换器设计工具;4、大型介质材料库;5、波导型号库;6、天线设计数据管理;7、基于天线模板的用户自定义天线库管理Antenna Magus 2017 Professional | 1.5 GbMagus (Pty) Ltd.

and CST – Computer Simulation Technology AG (CST) announce the release of Antenna Magus 2017, the latest version of the leading antenna design tool.

The latest edition includes several new antennas and design updates.

Antenna Magus includes over 300 antennas, and the Specification-based workflow introduced in 2016 allows users to find, design and export suitable antennas based on their requirements.

The 2017 version introduces 13 new types.

Four specialized horn antennas have been added – the smooth spline profiled pyramidal horn, the 4 waveguide-fed dual polarized pyramidal horn antenna, the waveguide-fed pyramidal array and the TEM horn with magnetic dipoles (or “Koshelev antenna”).

There are also five antennas commonly used in RF application notes and reference designs.

These are standard antennas such the PIFA and the meandering monopole, which are provided by RF component manufacturers for testing during product development.

With Antenna Magus, these can now be customized for different frequencies or different substrates, and parametric models can be directly created for 3D simulation with CST STUDIO SUITE.

Finally, there are four other antennas for special applications: the square truncated capacitively -pinfed circularly polarized patch, the self-phased backfire quadrifilar helix, the six mode loop antenna and the center-fed linear resonant waveguide slot array with longitudinal broad-wall slots.

The 2017 version also sees improvements to the Specification and Array Design workflows to streamline the design process.

In addition, Antenna Magus is now entirely 64bit and various performance improvements have been made to individual features.

Meanwhile, CST customers who have both CST STUDIO SUITE and Antenna Magus can now manage both licenses within the same tool.

About MagusMAGUS (Pty) Ltd develops antenna design and information management software.

Antennas designed using its software can be used in a wide variety of applications at various frequency bands, including, but not limited to, telecommunications, mobile devices, aerospace, satellite, automotive, radio astronomy and defense.

About CST- Computer Simulation Technology AGFounded in 1992, CST is a market leader in delivering 3D electromagnetic (EM) field simulation tools through a global network of sales and support staff and representatives. CST develops CST STUDIO SUITE, a package of highperformance software for the simulation of EM fields in all frequency bands. Its growing success is based on a combination of leading edge technology, a user-friendly interface and knowledgeable support staff. CST solutions are used by market leaders in a diverse range of industries, including aerospace, automotive, defense, electronics, healthcare and telecommunications. On September 30 2016 CST joined the SIMULIA brand of Dassault SystèmesProduct:Antenna MagusVersion:2017.xSupported Architectures:x64Language:englishSystem Requirements:PCSupported Operating Systems:Windows 7even / 8.1 / 10 / Server 2012 R2Software Prerequisites:CST STUDIO SUITE 2017.01Size:1.5 Gb


Antenna Magus 2017.3 Professional的图片1
Antenna Magus 2017.3 Professional的图片2
Antenna Magus 2017.3 Professional的图片3
