RAM Concept CONNECT Edition V6 Update 3 | 403.5 mb

Bentley Systems Incorporated, the leading company dedicated to providing comprehensive software solutions for sustaining infrastructure, has released RAM Concept CONNECT Edition Update 3, is an analysis and design program that uses the finite element method for elevated concrete floor systems, or mat foundations. The floors or mats can be post-tensioned concrete (PT), reinforced concrete (RC), or hybrid (a mixture of PT and RC). RAM Concept is extremely powerful and allows you to design an entire floor in one model, or design individual strips or beams.

In this context, the term "design" means that:

- The user defines the following: structural geometry, loads, load combinations, and post-tensioning layout (if applicable).

- RAM Concept calculates (for any number of load combinations): the required amount of reinforcement for flexure and one-way shear according to relevant code requirements; the stud shear reinforcement (SSR) for punching shear, stresses for flexure, and deflections.

A model consists of anything from a single simply supported beam or slab to an entire floor. All models are three-dimensional (even those developed with Strip Wizard).

RAM Concept does not generally use strip methods other than to replicate the intent of concrete code rules, and with the Strip Wizard interface.

Product:

RAM Concept

Version:

CONNECT Edition V6 Update 3 (version 06.03.00.006)

Supported Architectures:

x64

Website Home Page :

http://www.bentley.com

Language:

english

System Requirements:

PC

Supported Operating Systems:

Windows 7even and above

Size:

403.5 mb
