Autodesk Inventor HSM 2018.x | 382.8 mbAutodesk Inc.

, a world leader in 3D design software for entertainment, natural resources, manufacturing, engineering, construction, and civil infrastructure, has released Inventor HSM 2018.

2.

1 (R3) Build 5.

3.

1.

63, is an integrated 2.

5- to 5-axis CAD/CAM programming solution for Inventor.

This release contains a number of important fixes and improvements, as identified below.

Fixed issue with folder selection dialog. #8770Avoid showing Maximum Groove Stepdown and Grooving Pattern when roughing passes are disabled for Turning Profile Groove. #8711Fixed support for post processing to files that do not have a file extension. #8722Reenable display of file name in post process dialog. #8784Fixed incorrect turning holder display in setup sheet. #8628Fixed crash when press Enter key while Simulation active. #8667Disable insert position marker functionality (beta mode). #8813Updated translated strings. #8505Changes in toolpath generation:Fixed wrong roughing toolpath issue for Turning Groove. #8511Changes to post processor:Fixed missing unit mapping for Section.getParameter() API for number parameters. #8724Fixed missing properties for CurveEntity API. #8766Fixed error during cycle time calculation when there is a Z-plane probing cycle. #8551Fixed issue with unsupported tool orientation for machine when post processing. #8772Changes to post library:Fixed wrong syntax for canned cycles for XML post.

Fixed missing indexing of C-axis in XCZ mode for HAAS mill-turn posts.

Fixed missing option for G18 property for Milltronics post.

Fixed homing of the C-axis at the end of the program and disabled the output of G80 after a part transfer operation for Doosan mill-turn Fanuc post.

Fixed helical move issues for MillPlus post.

Fixed probing cycles for Heidenhain posts.

Fixed helical move issues for Siemens mill posts.

Fixed wrong coolant M-codes for CNC Router Parts (Mach3Mill) post.

Fixed tapping with chip breaking for UCCNC posts.

Fixed issue with missing wrap of listed tools for HTML setup sheets.

DATRON MCR English/German posts are now deprecated.

Use the DATRON MCR post instead.

Adjusted parameter output to exclusively use type attribute for differentiating between types for XML post.

Switched from using G53 to G28 for machine retracts for TinyG post.

Updated multi-axis rewind handling to allow for resetting of the encoder and handling of continuous axes for HAAS posts.

Added documentation of properties for HAAS posts.

Updated multi-axis rewind handling to allow for resetting of the encoder and handling of continuous axes.

Major update of DATRON next post with improvements and fixes.

Major update of DATRON MCR post with improvements and fixes.

Added Mazak laser post.

Added feedrate support for Mach3 waterjet post.

Added property to use pitch for tapping for Mazatrol Fusion 640M post.

Added documentation of properties for HAAS mill-turn posts.

Added support for BC-style trunnion for HAAS Next Generation posts.

Added support for 5-axis trunnion, subprograms, probing, nano smoothing, and center part at door for Doosan VMC Fanuc post.

Added new property ‘TCPType’ to control the TCP type for OSAI post.

Added property ‘useG0’ to turn on/off G0 rapid moves for Pocket NC post.

About Autodesk Inventor HSM.

Autodesk HSM 2018 software bundle provides the best value in integrated CAM software available.

Included are HSM add-ons for SOLIDWORKS and Autodesk Inventor.

Integrated CAM helps CNC programmers, designers, and engineers rapidly produce machined parts in one seamless workflow, while maintaining model associativity for quick updates to part changes.

Whether you are working with multiple CAD formats or starting from pencil sketches, Integrated CAM with your design software is the simplest and fastest way to machine your parts.

Take advantage of the best-in-class toolpath strategies for 2.

5D, 3D and 3+2 milling applications.

Inventor HSM software not only provides all the conventional machining strategies, but it also generates smooth linking moves that reduce machining time and increase machine and tool life.

About Autodesk.

Autodesk helps people imagine, design and create a better world.

Everyone—from design professionals, engineers and architects to digital artists, students and hobbyists—uses Autodesk software to unlock their creativity and solve important challenges.

Product:Autodesk Inventor HSMVersion:2018.xSupported Architectures:x64Language:multilanguageSystem Requirements:PCSupported Operating Systems:The same OS for the version of software that you are using.

Software Prerequisites:compatible with the 2016 or newer versions of Inventor Professional or Inventor LT.

Size:348.3 mb
