FLUX是专业的电、磁、热场分析软件，可用于各类电机、电器、传感器、舰船的分析，强大的后处理功能，提供可靠的技术支持服务,欧洲最流行的电、磁、热场分析软件.

FLUX

是一款针对于电机、传感器、变压器等电磁设备的专业二维及三维仿真软件。它基于有限元算法,主要用于电磁设备、热装置、热处理的分析与设计。主要应用领域有：电磁、电热、电子机械和驱动设备等。基本模块包括前处理（建模、物理属性设置、网格剖分）、求解以及后处理（结果显示、数据输出）。共有16大应用功能模块供用户选择。

FLUX® 允许用户使用Python命令流编写特殊的材料属性、定义驱动电源属性和定义边界条件，用以控制开发和执行特定的后处理任务。

FLUX_to_Simulink接口：用户可以通过Simulink接口将FLUX模型作为独立模块应用到其他专业仿真软件中进行更高级的分析，如：优化设计、电机起动的瞬时控制等。

这些功能使FLUX® 成为目前国际市场上最具灵活性的软件。

Altair

Flux 2018.0.0 | 1.3 Gb

The leading software for low frequency electromagnetic and thermal simulation, Flux, now a part of the Altair HyperWorks simulation platform, has released Flux 2018.0.0. This release is now fully part of HyperWorks and thanks to our flexible HyperWorks Units, users are now able to access even more tools that will help you to save time in your designs and enable powerful simulations.

Flux 2018 New Features:

- Accelerate your design when dealing with 3D complex CAD geometries

A number of new tools were introduced in Flux 12.3, which enabled the import of 3D meshes directly from HyperMesh and SimLab, bringing new capabilities for CAD geometry simplification and meshing. Flux 2018 improves the existing workflow, bringing more flexibility as well as making it applicable to any type of application.

The following functionality is available: change the order of the mesh elements, build an infinite box after import, account for movement, deal with any type of coil description or importing a surface mesh.

- Solving faster in 3D using new HPC capabilities

Improvements introduced in Flux 2018 focus on large 3D models with eddy currents.

. New mathematical formulations are now available to help the non-linear convergence in such cases, particularly in the frequency domain.

. The linear solver has also been updated with the latest version of MUMPS, and the possibility to use it in a distributed memory mode, allowing Flux to run on clusters with larger numbers of cores. This brings great accelerations for 3D models with large meshes.

. It is now also easier to benefit from the computing power of remote clusters thanks to the connection of Flux with PBS Works, Altair's industry-leading workload manager and job scheduler for high-performance computing.

- Going further in the coupling with mechanical simulation

The coupling with OptiStruct for mechanical design has been updated with the new version. For vibration analysis of electric machines, the post-processing capabilities of Flux have been extended with more options in the data visualization and export.

For static stress analysis, it is also now possible to export force densities from a magnetostatic model or from a step of a transient magnetic computation to a structural simulation. Not only magnetic pressures but also volumic Laplace forces can be calculated and exported to OptiStruct to compute mechanical stresses.

- Efficient power busbar design using Flux PEEC

The PEEC (Partial Element Equivalent Circuit) method is now directly available in Flux. Because this solver does not need any meshing of the air surrounding the parts, it is much more efficient than the finite element method to deal with sets of long or flat conductors. It is the tool of choice for the design of power busbars. Resistances, inductances and parasitic capacitances of conductors can be quickly computed and extracted for circuit simulation. Current, power or force densities distributions are natural outputs that can be used with thermal or structural solvers to analyze respective temperature distributions or mechanical stresses in the bars.

Note: For the full list of new and improved features, please refer to the release notes located in the folder of your

Altair Flux

2018 or here

here

About Altair Flux.

Flux is the leading software for electromagnetic and thermal simulations. For more than 30 years, Flux simulation software has been used worldwide in leading industries and university labs. It has become a reference for the high accuracy it delivers.

With its continuously improving technology, Flux is a versatile, efficient and user-friendly tool that will help to generate optimized and high-performance products, in less time and with fewer prototypes. Together with a highly qualified support network and a strong community of users, Altair and its Flux team provide recognized expertise in electrical engineering.

In a greener and more electric world, engineers can rely on Flux to assist in designing energy efficient devices, bringing more innovation and value to your customers.

Flux, using breakthrough technologies, is the right tool for the analysis, design and optimization of modern applications. Featuring embedded multi-parametric analysis capabilities, its open interface deals with different simulation domains and is well suited for multiphysics couplings.

About Altair.

Altair is focused on the development and broad application of simulation technology to synthesize and optimize designs, processes and decisions for improved business performance. With more than 2,000 employees, Altair is headquartered in Troy, Michigan, USA and operates 69 offices throughout 24 countries. Altair serves more than 5,000 customers across broad industry segments.

Product:

Altair Flux

Version:

2018.0.0 build 2336

Supported Architectures:

x64

Website Home Page :

http://www.altair.com

Language:

english

System Requirements:

PC

Supported Operating Systems:

Windows 7even or newer

Size:

1.3 Gb
