NI LabVIEW 2018 Sound and Vibration Analysis VIs | 563.0 mb

National Instruments (NI), has announced the release of LabVIEW 2018 Sound and Vibration Analysis VIs. Use the Sound and Vibration VIs to perform sound and vibration measurements. The Sound and Vibration VIs perform the selected analysis and allow you to view the results with the appropriate engineering units in standard displays such as magnitude/phase, real/imaginary part, and decibels on/off.

The Sound and Vibration Toolkit includes the following new features:

- Support for LabVIEW 2018

Support for LabVIEW 2018 does not remove previously installed support for LabVIEW 2017 and earlier.

- Test Signal Synchronization Pulse

Synchronization pulse can be used to time-synchronize multiple input channels with output channel.

- New Test Signal Properties

. Synchronization Pulse>>Enable Leading

. Synchronization Pulse>>Enable Trailing

. Synchronization Pulse>>Pulse Duration

. Synchronization Pulse>>Pulse Level

. Synchronization Pulse>>Pulse Type

. Synchronization Pulse>>Pulse Waveform

. Total Samples

. Remaining Samples

. Continuous Sweep>>Frequency Waveform

. Continuous Sweep>>Phase Waveform

New Examples

- Calibration examples to perform end-to-end channel calibration with dynamic sensors

- Signal generation examples to configure and generate test signals for stimulus-response tests

Product:

NI LabVIEW Sound and Vibration Analysis VIs

Version:

2018 version 18.0.0

Supported Architectures:

32bit / 64bit

Website Home Page :

http://www.ni.com

Language:

english

System Requirements:

PC

Supported Operating Systems:

Windows 7even SP1/ 8.1 Update 1 / 10 (version 1709) / Server 2012 R2 or Server 2008 R2 SP1

Software Prerequisites:

LabVIEW 2018 Full or Professional Development System, NI LabVIEW 2018 Real-Time Module

Size:

563.0 mb
