ContextCapture Editor CONNECT Edition V10 Update 2 | 3.7 Gb

The Bentley product team are pleased to announce the availability of ContextCapture Editor CONNECT Edition V10 Update 2 (version 10.02.00.24), is a comprehensive, scalable, and interoperable reality modeling application for producing 3D engineering-ready reality meshes for consumption in any engineering or GIS workflows.

Quickly create and share highly detailed 3D reality meshes using photos and/or point clouds, resulting in fine details, sharp edges, and geometric accuracy.

Streamline your workflows by directly accessing and streaming your reality meshes from ProjectWise ContextShare. You can easily extract features and analyze your reality data to perform calculate volume, extract ground, flatten areas, and more.

With the latest update, you can quickly create Scalable Mesh from terrain data and drape aerial imagery to enhance the display. And you can quickly compare point clouds with reality meshes when you display point clouds in cross section views using only a cut plane.

What's new in ContextCapture Editor CONNECT Edition V10 Update 2 (version 10.02.00.24):

Scalable Mesh

- Attach and display Bentley's new Scalable Mesh format.

The following tools have been enhanced to support this new Reality Mesh format:

. Sections

. Model by Section

. Ground Extraction

. Drape Element

. Snap Element

ProjectWise ContextShare integration

- ProjectWise ContextShare allows you to securely manage, store, and share large amounts of Reality Modeling data.

The ProjectWise ContextShare integration allows to:

. Convert local Reality Mesh to the Reality Mesh 3DTiles format and upload to ProjectWise ContextShare.

. Attach and stream Reality Mesh 3DTiles from ProjectWise ContextShare.

Volume Calculation

Analyze volume differences in a defined area between two Reality Mesh or a Reality Mesh and design element. The tool returns Cut and Fill volumes and a raster grid that can be displayed using existing thematic display functionalities.

Quick Ground Extraction

Extract terrain from an area of a Reality Mesh to a new Reality Mesh attachment and seamlessly display the result using clips.

Tile Terrain

Extract and tile terrain from a Reality Mesh to multiple Terrain Model elements or LandXML files.

Convert Reality Mesh

Convert 3MX files to Bentley's new Scalable Mesh format.

Generate Scalable Mesh from terrain data

Generate Scalable Mesh files containing terrain data from sources such as: DTM and TIN files, LandXML, DEM rasters, classified Point Clouds, Scalable Terrain Models and DGN elements.

Product:

ContextCapture Editor

Version:

CONNECT Edition V10 Update2 (version 10.02.00.24)

Supported Architectures:

x64

Website Home Page :

http://www.bentley.com

Language:

english

System Requirements:

PC

Supported Operating Systems:

Windows 7even or newer

Size:

3.7 Gb
