概念轨道设计软件- OpenRail ConceptStation
通过快速创建概念设计并改进决策制定流程来快速启动轨道项目。OpenRail ConceptStation 提供轨道、电气化、隧道和桥梁设计功能,帮助轨道工程师和设计师创建符合环境的智能模型。评估包含真实数据和成本分析的概念设计备选方案,快速确定最佳设计。
利用数据采集、实景建模和概念设计消除铁路网项目初步规划阶段存在的高成本、高风险项目。
使用 OpenRail ConceptStation,您可以:
从点云、三维实景网格、地形数据、图片和地理信息等大量资源中查找并在线下载数据丰富的环境信息,将真实环境融入您的轨道项目中。
将三维建模与简单易用的工程草图功能结合使用,快速进行概念化轨道、电气化、隧道和桥梁设计。
快速生成多个含有相关项目成本信息的设计方案,并与项目团队和利益相关方共享,以便选择最佳方案。
与公众和利益相关方共享逼真的可视化效果,进而收集反馈、提高公众参与度并加快项目审批.
OpenRail ConceptStation CONNECT Edition V10 Update 7 | 1.3 Gb
The OpenRail ConceptStation team is extremely happy to announce the new release of OpenRail ConceptStation CONNECT Edition. This software can help you plan the layout and design of new rail infrastructure faster than ever before.
About OpenRail ConceptStation CONNECT Edition.
Jump-start your projects by rapidly creating conceptual designs and improving the decision-making process. OpenRail ConceptStation offers track, overhead line, tunnel and bridge design capabilities to help track and overhead line engineers create intelligent models in context. Explore conceptual design options with real-world data and cost analysis to improve project results.
The following summarizes the features in OpenRail ConceptStation.
- Single Track
- Place single track.
- Multi Track
- Place multi track.
- Place Yard
- Define yard area.
- Offset Track
- Offset track.
- Turnout
- Place turnouts from library.
- Fit Turnout
- Fit turnout to rail crossing.
- Crossover
- Create rail crossover.
- Mast
- Place masts.
- Portal
- Place portals.
- Wire
- Place wires.
- Overlap
- Place wire overlap.
- Track Template
- Change track template.
- Existing Road
- Place existing road.
- Tunnel
- Place Tunnel tool.
- Culvert
- Place Culvert tool.
- Bridge clearance
- Check the clearance between a bridge and a rail track, or road.
- Auto Train Animation
- Automatically animate a train in visualization mode.
- Sharable Terrain Model
- New high resolution, scalable and sharable terrain model (3sm).
- Working with Reality Mesh
- Reference reality meshes from Bentley ContextCapture.
- Ground Extraction Tool
- To prepare a region of the 3D reality meshes to design your concept.
- Export -
Export to detail design
- Import ALG
- Select the template to be applied during the import process.
- Import 3D elevation
- Support 3D elevation during import process (OSM , SHP, DTM).
Product:
OpenRail ConceptStation
Version:
CONNECT Edition V10 Update 7 (version 10.00.07.27)
Supported Architectures:
x64
Website Home Page :
http://www.bentley.com
Language:
english
System Requirements:
PC
Supported Operating Systems:
Windows 7even or newer
Size:
1.3 Gb
Password/解压密码-0daydown
发布日期: 2018-08-30
