Altair Inspire Form 2019.1655 x64

CG数据库 >> Altair Inspire Form 2019.1655 x64

Altair Inspire Form 2019.1655 x64的图片1

Altair Inspire Form (原 Click2Form) 是一个完整的冲压仿真环境，产品设计工程师和工艺工程师们可以有效地利用它来优化设计、模拟稳健的制造工艺和降低材料成本。凭借快速且方便灵活的模块，用户可以在短时间内对零件进行分析，从而在产品开发周期的早期预测成型性。自动毛坯排样功能提供了在卷料上最大化材料利用率的高效的排样方案。工艺仿真模块包含灵活的增量法求解器，帮助用户在直观简捷的交互环境中实现多工序成型工艺的仿真、修边和回弹分析，简化工艺并更加经济地生产高质量的产品。

Altair Inspire Form 特征

几何创建和简化

利用 Altair Inspire Form 的几何准备工具可提取中面、填充孔洞及切口并移除法兰。此外，使用 solidThinking 的 Inspire 工具可创建并修改几何。

模型建立

若零件几何在车身坐标系中可用，Altair Inspire Form 即可自动计算最佳冲压方向。用户也可自定义冲压方向。同时，还可以应用压边和拉延筋相对应的约束阻力。

材料库

Altair Inspire Form 提供了包含标准钢牌号和铝牌号属性的材料库。还可以创建新材料并将其保存在用户数据库中。

分析和结果可视化

形成零件形状所需的扁平毛坯在分析结束时可用。可视化减薄和其他缺陷，如裂纹、褶皱和板料松弛区域。

多工序虚拟试模

通过单工序和多工序成型仿真工具优化产品制造工艺。快速且灵活的增量法求解器支持成型和修边等工艺，并提供精确的有关材料流动、开裂、起皱、松弛和回弹的结果。

Altair Inspire Form 2019.1655 | 1.3 Gb

Altair is pleased to announce the availability of Inspire Form (ex Click2Form) 2019 Build 1655, is a sheet metal forming simulation software that enables design engineers and cost estimators to optimize their products for manufacturing by considering formability, material utilization and cost.

About Altair Inspire Form (ex solidThinking Click2Form).

Inspire Form is a sheet metal forming simulation software that enables users to optimize their products for manufacturing, with the consideration of early formability, material utilization and cost. Evaluating feasibility within seconds is possible with the industry leading one-step inverse simulation technology. In addition to providing the users with areas of possible failure due to tearing and thinning, Inspire Form has comprehensive blank utilization capabilities that provides optimal blank shape including the best layout for blank nesting and the associated material cost.

About solidThinking.

solidThinking creates, develops, and markets technology that helps our user community bring the most desirable products to their customers faster. solidThinking software is sold and supported by a global network of distribution partners and is also available as part of the Altair HyperWorks® suite. solidThinking is a wholly owned subsidiary of Troy, Mich. (USA)-based Altair.

About Altair.

Founded in 1985, Altair is focused on the development and application of simulation technology to synthesize and optimize designs, processes and decisions for improved business performance. Privately held with more than 2,600 employees, Altair is headquartered in Troy, Michigan, USA with more than 45 offices throughout 20 countries, and serves more than 5,000 corporate clients across broad industry segments.
