3DQuickPress® is a SOLIDWORKS® add-on for progressive die design.

With a 3D solid model of the part, a 3D strip can be created quickly and easily, and also be communicated clearly throughout the work group using the free SOLIDWORKS eDrawings® viewer before further detailing of the die without time wasted.

Powerful UnfoldPowerful Unfold, a feature recognition technology, can handle native SOLIDWORKS® sheet metal parts for imported data, and provide a knowledge base for spring back and bend allowance.

Form features can save valuable time from die designs and give them more design productivity tasks.

Strip Layout ManagerStrip Layout Manager provides users with intuitive tools to quickly complete the strip simply by drag & drop command with instant graphical feedback.

Key functionsOptimizationSupport multiple partsNotch punch designSplit punchMismatch undercutsPartial bendInsert/Delete stationsReport on material utilization and center of cutting forceDie Set DesignDie Set Design begins after finishing the strip layout.

3DQuickPress® will automatically create all punches defined in the strip design.

Key functionsUser definable databasesAutomatic hole creationTools for component placementStandard components librarySupport compound die and transfer dieProduction-Ready-Libraries (PRL)PRL assists users to insert home-made components into die sets structure with minimal manual operations.

Key functions:Automatic punches & insert creationUser defined punches and insert creationStandard parts & die sets libraryCreate all openings in all plates automaticallyAutomatic parts recognition to create an accurate BOMSketch tools to assist in creating die openings and insertsThis hotfix only update 3DQuickPress version 6.

2.

0 to 6.

2.

7.

Please install 3DQP 6.

2.

0 version and apply this patch.

Whats New:Enhancements:1.

Dimension tolerance in axial direction for standard component holes.

2.

Update (if it exists) the value of Sort Balloons <3DQP-BOM-Qty> without changing Property Type.

Fixes:1.

Mouse mid-button scrolling not working for 3DQP Feature Manager in Windows 10.

2.

Problem with on stock in-place bend if attached to non-root feature.

3.

In-place bend has no effect on swap part in "On-Stock" option.

4.

Edit Transform Part function not shown.

5.

Stability problem when Stock Movement is enabled.

6.

Failure to create bending components with Auto-Reorganize Mode On.

7.

Performance issue When creating die set from punch design with SmartHoleSeries.

3DQuickPress for SolidWorks 2012-2019
