AutoPIPE Vessel CONNECT Edition V41 | 1.1 Gb

The Bentley team is pleased to announce the availability of Vessel (Powered by Microprotol) CONNECT Edition V41 (build 41.00.00.006), the Most Comprehensive Software for Vessel Pressure, Heat Exchanger, and Tank Design Optimization

What is New & Changed in AutoPIPE Vessel

CONNECT Edition v41 (build 41.00.00.006: Jan 2019)

Enhancements

- Codes/Standards Update

EN 13445-3:2014+A3:2017

CODAP 2015 revision 07/18

IS 1893 - 2015

- Legs Support

AISC Unity Check Method.

- Flanges

External loads can be defined on standard Nozzle Flanges (ASME Code Case 2901).

The Flange rigidity ratio can be defined by the user.

The Flange allowable stress factor can be defined by the user.

- Drawings

Added additional dimensioning sketches for TEMA types AHS / AJS Shell and Tube Heat Exchangers.

- User Interface

CONNECT Advisor: Contextual Tab - As you work in the product, content that is applicable to your current action is shown here.

- Expansion joint design based on Finite Element Analysis (FEA), in accordance with TEMA 9th edition, including stress linearization (based on ASME Sec. VIII, Div. 2, Part 5) and verification with ASME code allowable stresses, available on 64-bit OS only.

- Vortex Shedding Calculations [ Technology Preview ]

- CONNECT Licensing

- This product version utilizes CONNECT Licensing, which is not supported by SELECT activation key(s). CONNECT Licensing features new behavior to enhance your organization's user administration and security with mandatory user sign-in via CONNECTION Client to access the application. If you are already signed in to the CONNECTION Client, you have met this prerequisite. If you have not, please refer to the Administrator's Resource Center and/or contact your administrator for assistance in the registration and sign-in process.

About AutoPIPE Vessel.

AutoPIPE Vessel provides you with cost-effective and accurate design of pressure vessels, heat exchangers, tanks, and air coolers. Reduce mistakes and time consuming manual revisions. Ensure greater efficiency with your supply chain and improved collaboration with engineering companies. Increase your efficiency through fully automatic vessel design optimization under all installation and operating conditions.

Increase productivity and provide accurate design for the safe operation of vessels under all loading conditions for pressure vessels, heat exchangers, tanks, and air coolers. Achieve compliance with regional and global standards, including pressure vessel design codes from the past 10 years and regional wind, seismic, wave, and blast-loading codes. Improve flexibility for re-rating and revamping existing vessels. You can design for both brownfield and greenfield projects, and shorten design time and rework by eliminating guesswork. Ensure confidence in vessel design and improve your competitiveness through higher design quality.

About Bentley Systems, Incorporated.

Bentley is the global leader dedicated to providing architects, engineers, constructors, and owner-operators with comprehensive architecture and engineering software solutions for sustaining infrastructure. Founded in 1984, Bentley has nearly 3,000 colleagues in more than 45 countries, $500 million in annual revenues, and, since 2001, has invested more than $1 billion in research, development, and acquisitions.

Product:

AutoPIPE Vessel

Version:

CONNECT Edition V41 (build 41.00.00.006)

Supported Architectures:

x64

Language:

english

System Requirements:

PC

Supported Operating Systems:

Windows 7even or newer

Size:

1.1 Gb
