Simulis Thermodynamics 是以MS-Excel格式嵌入的热物理性能计算器，通过MATLAB工具条或者以模块方式嵌入到需要计算热物理性能的其它软件中。
一、软件用途及技术规格用途：所提供的化工热力学计算软件应该可以完成混合组份属性和流体相平衡计算。
可以为工程师或软件开发人员提供了精确可靠的热物理属性计算器。
软件还应当保证数据结果的一致性和可靠性，这些计算可以集成在任何软件包中，满足各种应用场合（设备尺寸计算、系统建模等）。
要求：软件包至少应具有下述功能：1、 可以用于计算物流的传递属性（热量、黏度等）；2、 可以用于计算物流的热力学性能（焓、压缩系数等）；3、 可以用于计算及多组份混合状态下的任何形式的相平衡（VLE、LLE、VLLE等）；4、 可调整用户系统的最佳热力学参数；5、 可以集成到客户的应用程序中；6、 可以使用标准的CAPE-OPEN接口；二、技术规格1. 包含石油加工过程中常见组份热力学性质的数据库；2. 提供用户二次开发接口；3. 可以根据混合物的蒸馏曲线采用虚拟组份法处理混和物流；ProSim Simulis Thermodynamics 2.0.25.0 with Component Plus 3.6.0.0 | 471.9 mbProSim has launched Simulis Thermodynamics 2.
0.
25, is a calculation server for thermophysical properties and phase equilibria calculations on pure components and mixtures.
What’s new in Simulis Thermodynamics 2.0.25:– New management of databases of binary interaction parameters: the user can now create his own private databases of binary interaction parameters in Simulis Thermodynamics.
It also gives the possibility to choose among the databases at its disposal, the binary interaction parameters to be imported into its calculator.
– Possibility to define all of the electrolytes models as “True species” ones: speciation reactions used in reactive models are equilibrium reactions by default.
If the user wants to describe a speciation reaction controlled by kinetics, it can’t be described in the thermodynamic calculation server.
So, all reactions must be computed inside the unit operation using, for instance, a reactor or a reactive flash or a distillation column in ProSimPlus, or by describing the model in Matlab or Excel.
– The calculation of the critical point of a mixture is now possible for most of the models which are based on a homogeneous approach (equations of state).
– SRK-KD model: the binary interaction parameters can now be entered directly in the calculator interface so that the default values are not used, which offers more flexibility and the possibility of fitting these parameters.
– PPR78 model: improved calculation performances.
– Update of reactive model databases.
Product:ProSim Simulis ThermodynamicsVersion:2.0.25.0 with Component Plus 3.6.0.0Supported Architectures:x86Language:french, english, russianSystem Requirements:PCSupported Operating Systems:Windows 7even or newerSize:471.9 mb
