SAP 3D Visual Enterprise Author是一款功能非常强大的2D3D模型浏览和转换的文件;它可以帮助用户加快决策的速度,提高质量、生产力的优化，集成了3D数据业务在流程里的流程链，包含了子对象、图形中的纹理位图的数量、顶点、平移、缩放探索3D模型、旋转、灯光、摄像机、查看对象的信息的等.

SAP 3D Visual Enterprise Author 9.x | 701.6 mbSAP AG, multinational software corporation that makes enterprise software to manage business operations and customer relations, has released an updated (FP03) 3D Visual Enterprise Author 9.

0.

This software for create 3D animations and render rich visual content into common desktop documents, file formats, and business applications for secure downstream use.

SAP 3D Visual Enterprise Author 9.0 FP06 – release notes:General (Enhanced)This release contains general stability and performance improvements, and bug fixes.

Step Subtitles (Enhanced)Steps Subtitles support is added to the Standard (VDS) Layout.

Authored Content Merge Support (Enhanced)When you add a VDS file to an existing model, new and modified content is correctly merged.

Translation of External IDs from RH to VDS (Enhanced)External IDs added by SAP 3D Visual Enterprise Generator to RH files are translated to VDS.

Callouts Tool Update (Enhanced)The Callouts tool is extensively enhanced.

You can now select multiple metadata attributes to display.

Additionally, there is a new Billboard setting to control the scaling of callouts.

Notes Tool Update (Enhanced)The Notes tool is extensively enhanced. The following options are added:.

A new Billboard setting to control scaling of Notes.

.

The ability to create a 45-degree break in leader lines and to scale Leader Points.

. An Open Arrowhead option.

A new user interface for the Rich Text Tool.

Measurements Tool Update (Enhanced)The Measurements tool is extensively enhanced. There are the following extra options:.

A new Settings window with Styles support.

.

The Tool Inspector Measurements panel has an updated user interface.

.

New settings to comply with ASME standard to control positions of text, arrows, and leader lines.

. New Features available for selectionFixed Axis Widget Support (New)There is a new option to pin the Scene Axis widget to the left bottom corner of the Viewport.

User-defined Axis Primitive (New)There is a new option to override Axis names in the 3D Axis primitive.

You can access the 3D Axis primitive from the Object Properties window.

Metadata Hyperlinks Support (New)Hyperlinks are now supported in the SAP 3D Visual Enterprise Author Metadata Panel.

CAD (Enhanced)The CAD importers were updated as follows:.

CATIAV5 file format: R28 support.

.

Inventor file format: 2019 support.

.

IFC file format: IFC 4.

.

All formats: Precision optimization in tessellation routines.

As a result there are some changes in vertex count which are under an acceptable threshold.

. NX file format:.

.

If NX files are saved with Face Edges option in the NX application, importing Model Views show “Solid”, “Solid Outline”, and “Wireframe”.

.

.

PMI extended font support (Bold, Italic, and Italic Bold).

.

.

Import option default change – Always Show PMI on Top has default “NO” *.

. IFC file format:.

.

Unit of measure is added to metadata values – Category: Basic quantities.

.

.

VE Component ID and VE Instance ID are replaced with Global ID.

. General Fixes and Enhancements:.

.

NX file format: Fixes to the following areas – PMI leader line arrow types, text size, metadata, cross section, set leader line curve style.

.

.

Inventor file format: Fixes to the following areas – Assembly Pattern feature, sheet metal parts, transparency on parts, cases with no material, handling of surface body and loft surfaces.

.

.

JT Viewer file format: Fixes to the following areas – assembly tree, assembly PMI connections, PMI sections, JtBREP, and mesh material.

.

.

JT/PLMXML file format: Refactored JT import /export functionality.

.

.

CATIA V5 file format: Fixes to the following areas – Improved Line type handling for 3D wireframe, improved section view, Axis line, and hatches clipping processing.

.

.

Creo file format: The Creo reader now processes both mesh and generic representation of family parts with new library whereas old ones were only reading mesh representation so the performance has degraded.

.

.

ACIS file format: Improved process to enable projection of 3D curves on surfaces for better curvature continuity.

This process produces NURBS with more points, and consequently the realignment process is more time consuming.

. All CAD formats sort model views based on namesAbout SAP SE.

SAP SE (SAP) is a software and service provider.

The Company offers enterprise application software.

The Company operates through two segments: Applications, Technology & Services segment, and the SAP Business Network segment.

The Applications, Technology & Services segment is engaged in the sale of software licenses, subscriptions to its cloud applications, and related services (primarily support services and various professional services, and support services, as well as implementation services of its software products and education services on the use of its products).

The SAP Business Network segment includes its cloud-based collaborative business networks and services relating to the SAP Business Network (including cloud applications, professional services and education services).

Within the SAP Business Network segment, the Company markets and sells the cloud offerings developed by SAP Ariba, SAP Fieldglass and Concur.

Product:SAP 3D Visual Enterprise AuthorVersion:9.xSupported Architectures:x64Language:englishSystem Requirements:PCSupported Operating Systems:Windows 7even or newerSize:701.6 mb
