Solid Edge ST5

Solid Edge是Siemens PLMSoftware面向主流设计市场而推出的二三维一体化设计分析软件。凭借在零件建模、钣金设计、大装配设计、产品制造信息、工程出图、价值链协同、内嵌的有限元分析和产品数据管理等领先优势，赢得了机械、电子、航空、汽车、仪器仪表、模具、造船、消费品等行业的大量忠实客户。

自同步技术在2008年应用到Solid Edge以来，ST1主要表现支持机械设计，ST2支持钣金设计，ST3支持混合设计及塑料件、铸件设计，ST4更方便地导入其他软件生成的三维模型数据，今天即将与大家见面的ST5继续深化同步建模，推出多体建模方法、iPad应用等，增加了1300多个来自用户需求的新功能，可以说，ST5让同步建模在Solid Edge中发挥了其独特的优势。

•更加灵活地应用同步建模技术

•提供稳态的热分析仿真功能

•完善大量的工程制图的细节功能

•超过1300多项来自用户需求的新功能

•推出Insight XT，提升图档管理能力

Siemens PLM Software, a business unit of the Siemens Industry Automation Division and a leading global provider of product lifecycle management (PLM) software and services, announced the release of Solid Edge ST5, with advances in core design capabilities aimed at helping users develop better products faster. The latest Solid Edge release also contains more than 1,300 new customer-driven productivity enhancements.

Siemens PLM Software also announced Solid Edge Mobile Viewer, a new free 3D viewer mobile device application (app) for the iPad portable digital device, which broadens access to design data to help companies enhance collaboration.

Faster more flexible ways to use synchronous technology

Solid Edge continues to leverage synchronous technology, Siemens PLM Software鈥檚 breakthrough history-free, feature-based design technology for digital product development, to provide designers and engineers a better way to create and edit designs and to help cut design time by enabling reuse of imported models. Solid Edge ST5 uses synchronous technology to provide enhanced support for multi-body modeling, which lets users import parts and assemblies from virtually any CAD system. The resulting imported geometry can be combined into a single part or multiple parts depending on manufacturing requirements.

Continues to simplify drawing documentation

In many design and manufacturing companies, drawings are a key deliverable. Solid Edge enhancements continue to focus on drawing productivity to help lower shop floor errors. Enhancements in Solid Edge ST5 include the ability to show an assembly in multiple positions within a drawing view, to automatically place parts lists across sheets, and easily align the position of dimensions. A new marquee feature is the ability to create nailboards of electrical wiring harnesses, complete with flattened and 鈥渂end鈥� views, drawing views of connectors, and connector and conductor tables for creating complete manufacturing documentation.

Delivers thermal analysis for steady-state simulations

Engineers often need to simulate both thermal and mechanical systems where a part may have to undergo both stress and a thermal load. And when issues are encountered, they require a fast, easy approach to making changes that improve design quality. Solid Edge ST5 now includes steady-state thermal simulation and when coupled with synchronous technology users can test more alternatives in less time, so designers can reduce the need to build and test physical prototypes.

Solid Edge Mobile Viewer App for the iPad

Users across a company now have the ability to view 3D parts and assemblies created with Solid Edge using the new free Solid Edge Mobile Viewer app on an iPad. The app includes the ability to rotate, pan, zoom, show and hide parts, create and email images. Solid Edge Mobile Viewer allows individuals outside of the traditional design and engineering departments to view design data, enabling faster, more convenient design reviews, customer presentations, or general model inspection.

For more information please visit: http://www.plm.automation.siemens.com

About Siemens PLM Software

Siemens PLM Software, a business unit of the Siemens Industry Automation Division, is a leading global provider of product lifecycle management (PLM) software and services with seven million licensed seats and more than 71,000 customers worldwide. Headquartered in Plano, Texas, Siemens PLM Software works collaboratively with companies to deliver open solutions to help them make smarter decisions that result in better products.

About Siemens Industry Automation Division

The Siemens Industry Automation Division (Nuremberg, Germany) supports the entire value chain of its industrial customers 鈥� from product design to production and services 鈥� with an unmatched combination of automation technology, industrial control technology, and industrial software. With its software solutions, the Division can shorten the time-to-market of new products by up to 50 percent. Industry Automation comprises five Business Units: Industrial Automation Systems, Control Components and Systems Engineering, Sensors and Communications, Siemens PLM Software, and Water Technologies.
