《自动化运动控制系统调试软件》SIMOTION SCOUT 4.3 incl. SP1 with DriveES 5.5 SP1带驱动下载

SIMOTION SCOUT是用于调试SIMOTION的工具软件，需要授权。SCOUT工程开发系统的具有良好的用户友好性。运动控制、逻辑控制与工艺控制的工程开发，以及驱动器的组态与调试，均是由一个系统完成的。实际上所有任务的处理均可用图形方式完成，包括组态、编程、测试及调试。智能的用户提示信息，实用的帮助功能，自动的检查功能简化了任务的完成过程，特别适合于第一次编制运动控制程序的用户。SCOUT的所有工具均被集成在一起，并具有统一的形式及感觉。

集成在SCOUT中的STARTER主要能实现以下功能：

1、硬件组态和识别（电子铭牌）

2、 驱动参数的设置

3、 电机动态特性的调试

4、 故障诊断

5、 程序的下装和上载

而作为控制系统的工程工具，SCOUT除了能实现以上功能外，还能进行以下工作：

1.轴控制参数的设定

包括轴的机械参数、回零点方式及运动性能参数的设定。

2.控制程序编辑

包括运动控制、逻辑控制以及工艺控制。运动控制任务的图形化编程运动控制图 (MCC)可以以流程图的方式对机器程序顺序进行图形化编程。程序细节可以由LAD及FBD编程，对于复杂的逻辑控制、数学运算及运动控制还可以用ST结构化编程语言进行编程。这三种编程方式均可以集成在SIMOTION系统中。

3.凸轮曲线设定

在SCOUT基本软件包中已经了包含简单的凸轮文本编辑器，此外作为可选软件包，CamTool还可以为SCOUT提供全图形化的凸轮编辑及优化工具，可以集成在SCOUT的图形化用户接口中。

The SCOUT project navigator is the common frame for all tools of the engineering system. This workbench is therefore the navigation center for the individual engineering steps. It is used for creating and managing SIMOTION projects and offers a uniform view of all data and programs. The major innovation is the graphic motion control via Motion Control Chart.

Software Package included:

- DVD1: SIMOTION complete setup 4.3 SP1 HF1

Disk1 contains the complete setup to install the components of the software package.

CD_1-5 SIMOTION SCOUT 4.3 SP1 HF1: Installation of SIMOTION SCOUT V4.3 SP1 HF1 incl. online help

SIMOTION SCOUT Add-on 4.3 SP1 HF1

The Addon directory contains important information on V4.3 SP1 HF1, the SIMOTION Kernel V4.3 SP1 HF1 for all platforms, the Firmware Support Package V4.3 SP1 HF1 (installation of the FWSP in SCOUT for the device update tool) as well as all the information on SIMOTION IT (at 4_Accessories).

SIMOTION extensions, CamTool 3.0 SP2

The CamTool software is for the easy creation of cams. CamTool is an optional package for SIMOTION SCOUT and must be licensed separately.

A new upgrade license is required for CamTool V3.0 SP2 compared to previous versions before V3.0.

SSP_CD1/SSP_INT_CD1 SINAMICS Support Package

Additional SINAMICS firmware versions are stored as SINAMICS Support Packages (SSPs).

The contents of SSP_CD1 can be selected individually for installation via the SCOUT setup.

It is also possible to install the SSPs contained on SSP_CD1 individually at a later date.

Read the information provided on the SSPs in SSP_CD1\SSP_name\01_Readme\.

The contents of SSP_INT_CD1 are installed automatically.

- DVD2: DriveES Basic 5.5 SP1

The DriveES Basic software can be installed on the engineering computer of SCOUT for the configuration and commissioning of the MASTERDRIVES and SIMODRIVE drive components.

The DriveES Basic software is licensed for use with this SCOUT license.

Please note that with the installation of DriveES Basic, STARTER cannot be installed, as simultaneous operation of SCOUT and STARTER is not possible. It should therefore not be selected for installation. The installation for DriveES can be found on DVD2 in the DriveES_Basic directory.

SIMATIC NET V7.1 SP3 (SIMATIC NET, PC software, Edition 2008 SP3)

The correct SIMATIC NET version for the SIMOTION P V4.3 SP1 HF1 is supplied without license with SCOUT. For use, a license must be ordered separately.

- DVD3: Documentation 4.3 SP1 HF1

The Documentation directory contains the SIMOTION documentation in German, English, Italian and French in PDF format.
