许多模具制造者依赖于 2D CAD 方法来设计模架。因此，Creo Expert Moldbase Extension 提供了一个理想的解决方案。此软件基于过程并且易于学习，它使模具制造者能在熟悉的 2D 环境中工作，同时利用 3D 的所有强大功能和优点，从而显著地缩短了提前期。功能和优势   ·通过由过程驱动的简单工作流程自动完成模架设计和细化，从而加快设计速度    ·包含 17 种模架/组件（例如螺钉、顶杆、滑块、冷却接头）的供应商的库    ·自动顶杆、水线和接头功能，自动完成流道和水线检查    · 通过 3D 环境消除了许多错误，从而防止了昂贵的返工开销并缩短了周期时间    ·  通过自动更新模具模型、绘图和电极减少了对重新设计的需求

With Creo Elements/Pro Expert Moldbase Extension you can create mold base designs in a process-driven, familiar 2D GUI and automatically generate a 3D model to check for interference during mold opening. Automated design steps as well as libraries with numerous standard parts and components drastically speed up the entire development process.

Creo Elements/Pro Expert Moldbase Extension supports the efficient design of injection mold tools and as an ideal addition to Creo Elements/Pro Tool Design Option (TDO). While TDO concentrates on the design of core and cavity EMX allows extremely efficient design of the entire moldbase, including typical functional units like ejector pins, screw connections, cooling etc. Thus design time for mold tools can be reduced dramatically.

- Specialised 2D GUI for instant customisation of moldbases and components

- Automatic assembly of components – ‘pick & place’ ease

- All necessary clearance holes, threads, counterbores, etc. are automatically added to plates

- Part-level features already fully dimensioned

- Custom components can be created, saved and reused

- Automatic layers and simplified representations for easy viewing

- Standard and nonstandard mold components are marked

- Ability to take your customer parts through the complete process

- Supplier catalogs include: DME, DMS, EOC, FUTABA (Misumi), HASCO, KLA, MEUSBURGER, PEDROTTI, RABOURDIN, STRACK, PROGRESSIVE, NATIONAL, PCS and others

- Automatic functions for: Complete Moldbase Assemblies; Plates and Insulation; Guide, Leader and Return Pin Assemblies; Multi-Cavity and Family Molds Supported; Support Pillar Assemblies; Latch Lock Assemblies; Locating Rings and Sprue Bushing; Ejector Pins, including Sleeve Ejection; Screws and Washers; Dowel Pins; Cooling Circuit with Fittings, Plugs and O-Rings; Slider and Lifter Assemblies

- Automatic Drawing, Hole Chart and BOM Creation

- Mold Opening and Ejection Simulation

- Capturing Company Specific Best Practices and Standards in catalogues

About PTC

PTC is all about helping discrete manufacturers succeed by meeting their globalization, time-to-market, and operational efficiency objectives in product development. As one of the world's largest and fastest-growing software companies, we deliver a complete portfolio of integral Product Lifecycle Management solutions to over 25,000 customers in the Industrial, High Tech, Aerospace & Defense, Automotive, Consumer, and Medical Device industries.

Our people and technology enable teams to collaborate across departments—and across continents—helping you create innovative products that meet your customer needs and comply with industry regulations. In addition to best-in-class solutions, we also deliver expert training, software support, and world-class services both through PTC Global Services and a vast partner ecosystem--so you get the maximum value and ROI from your PTC software. Whether you’re a small or mid-sized business looking to migrate from 2D to 3D, or a global enterprise managing multiple product lifecycles, you’ll find exactly what you need with PTC -- the Product Development Company.
