Delcam FeatureCAM是基于特征、基于知识、使用自动特征识别技术的全功能智能CAM系统。独特的基于特征、基于知识的加工功能组合使得用户可以在最短的时间内、接受最少的培训的情况下，自由创建稳定、可靠的刀具路径。强大的自动特征识别功能，加速了从设计到加工的全过程。使用它使零件加工编程更方便，更简单，可极大地缩短加工编程时间，加工管理也更加有效.高附加值；机床运动三维仿真；支持主流 CAD 模型输入；自动特征识别；基于特征、基于知识的技术；全中文界面，易学易用。

Delcam launches the 2013 release of FeatureCAM feature-based CAM software. This will offer a new series of options for three-axis milling and enhancements in five-axis machining, plus improvements in the turning and mill-turn modules.

FeatureCAM was the world’s first feature-based programming software when it was launched in 1995. Constant development since then has ensured that the system has retained its leadership in programming speed and ease of use, while an increased range of strategies has been added to provide more efficient toolpaths giving greater productivity on a wider range of machines.

The main change to the 2013 FeatureCAM product family has been the introduction of three levels of 3D machining functionality. FeatureMILL 3D Lite offers single-surface machining with a basic range of strategies and so provides an introductory product for companies moving into 3D machining for the first time.

FeatureMILL 3D MX provides a greater number of strategies, including spiral finishing, flowline finishing and rotary machining, support for multiple-surface machining and automated feature recognition. It is aimed at companies with conventional machine tools and those that are machining softer materials.

FeatureMILL HSM also contains all of the options for rest machining, such as pencil machining and corner clearance, and high-speed machining, including trochoidal machining and Delcam’s patented Race Line Machining. It maximises the benefits of any investment in high-speed mills with strategies that maximise machine productivity while protecting the part, machine and cutter from excessive wear.

FeatureCAM HSM also includes a number of new strategies. Step cutting has been added within area clearance to remove large terraces that can be left on the part when using deeper roughing cuts. FeatureCAM will now produce extra toolpaths that step back up the terrace with the existing large tool, adding extra cuts at intermediate levels. This results in more material being removed, using the same tool within the same toolpath.

Automatic splitting of finishing between steep and shallow areas of the part has been available in FeatureCAM for a number of releases. This option has been enhanced with the ability to use the scallop height to control the stepover. Using this value rather than setting a constant stepover distance gives better control of the surface finish.

Both roughing and finishing strategies now incorporate an "area filter” to remove small enclosed pockets within the part from the toolpath. Any attempt to cut these areas risks damage to the tool, even though it is mathematically possible to remove the material.

New five-axis strategies available in FeatureCAM 2013 include flowline machining between two curves, pencil machining and corner re-machining. These options for simultaneous five-axis machining allow a better surface finish to be achieved as well as ensuring access to more areas within the part in a single set-up.

New options have also been added to give smoother five-axis machining. A new look-ahead capability will remove any sudden tool-axis changes during automatic collision avoidance and, instead, ensure that a smooth transition takes place. In addition, FeatureCAM now offers the ability to smooth the Azimuth and Elevation axes independently and so remove excessive five-axis movement. These options stabilise the rotary axis movement by maintaining a fixed tool axis as far as possible, thus replacing constant five-axis movement with a series of 3+2-axis segments having full five-axis transitions between them.

A number of enhancements have been added to FeatureCAM’s turning and mill-turn modules. Definition of the initial stock and part alignment has been improved, making it more similar to the set-up process for milling, support has been added for semi-finish canned cycles and curves of revolution can now be recognised from STL models. A new method has also been introduced allowing b-axis rotary milling to be carried out on features that would otherwise require the use of excessively long cutters.

The options for multi-spindle, multi-turret machines have been improved by fully integrating part transfers into the FeatureCAM output. Simulation and post-processing of these operations is also supported. In addition, the handling of synchronisation points has been enhanced to simplify the optimisation of the machining sequence between the various elements of the machine.

About Delcam plc

Delcam is a world-leading developer and supplier of advanced CADCAM software, with more than 35,000 customers in over 80 countries. These clients vary from global names like Nike, Boeing and Mattel to small start-ups and individual craftsmen. Founded 30 years ago, we are the largest developer of product development software in the UK, with subsidiaries in Europe, America and Asia. Our global success has been recognised with many awards, including three Queen’s Awards for Enterprise in the last six years.
