CATIA V5-6R2013 P2 - 该平台为用户提供最高质量的设计和独特的机会，在V5和V6 fichersy为用户提供V5-6R2013访问到关键V5-6R2013和V6 V6发动机和高的同步项目sozdvnnyh中的独特的兼容性 - CATIA V5和V6保障水平之间的合作.

在CATIA V6R2012X中创建的3D模型，可以转让V5-6R2012，留住他们的关键功能特性，而这些是可以改变的直接fichersy在V5。一个迭代的方法来设计工程师提供了最大的机会，创建和修改的详细fichersy，无论他们是否使用CATIA V5或V6。由于这一改进，CATIA V5和V6 CATIA的三维模型中的兼容性今天是高于两个发行版之间的V5。

一个新层次的合作，通过一系列的技术，为用户V5 V67这些增强功能为用户提供即时V5的优势，让很多功能以前只在CATIA V6。这些包括曲面造型和设计的部分设计的V6，现在已包含在V5-6R2013的机会。因此，我们的客户保持在V5的投资回报率，同时接收一个学习的机会在自己的步伐有利于开放的投资组合V6。这将提供机会之间的同步的释放V6和V5，从V6R2012x和V5-6R2012。旨在反映了独特的兼容版本V5和V6，同步发布V5和V6和V5系列的补充技术的V6版本名称的变化（从V5 V5-6）。

各种行业的机会，通过大量的更新发行版CATIA V5-6R2013)

完全集成的解决方案在汽车行业A级曲面建模 - CATIA的ICEM形状设计的表面质量最高的汽车车身和更好的用户体验的设计 - CATIA想象和形状行业标准的广泛支持和长期归档通过使用STEP格式进行数据交换，大型装配体和零件制成的复合材料表面机械仿真技术的持续改进。

新产品3D透视

改进后的产品功能建模零件.

新CATIA分析模块和SIMULIA扩展的分析加工硬质材料的新策略，为航空航天工业在CATIA加工“高级”：模块材料去除仿真和先进的后整理.

In April 2012, Dassault Systemes announced the industry’s best multi-version compatibility, allowing V5 and V6 users to share and edit parts at the feature level. OEMs or suppliers in all industries gained the flexibility to modify and exchange designs, whether they are V5- or V6-native, as they progress through the design process. V5-6R2013 extends the scope of this capability to include features created in the Freestyle workbench. V6 parts created in V6R2013x containing features created in the Freestyle workbench can be transferred with all their specifications to CATIA V5-6R2013. V6 models can be transferred “as specifications” to V5, retaining features created in, for example, V6’s Part Design, Sketcher, Generative Surface Design, and Freestyle workbenches and knowledgeware. This extension demonstrates the continuing compatibility and synchronization between V5 and V6, as well as the enrichment of V5 solutions with select V6 technology. To continue to support this synchronization, this release now contains over 40 new Part Design, Sketcher, and Surfacing functions that were originally developed for CATIA V6R2013 and V6R2013x.

CATIA Composites Fiber Modeler (CFM)

CATIA best-in-class composite solutions integrate the design, analysis, and manufacture of structures made from fiber-reinforced materials. CATIA Composites Fiber Modeler (CFM), a new product in CATIA V5-6R2013, provides robust and accurate fiber simulation to optimize ply shapes and ensure accurate manufacturing. This proven and widely-used technology from Simulayt, acquired by Dassault Systemes in October 2011, is now fully integrated into CATIA V5. Real-world components incorporate awkward features like sharp corners, splits, and rapid changes in curvature. These requirements quickly trap fiber simulation tools that have not been developed with real geometry in mind. The Simulayt technology is routinely used to analyze complex surfaces, particularly in the aerospace, helicopter, and motorsport industries. For example, the majority of successful Formula 1 cars are developed using Simulayt technology.

CATIA 2D Layout Browser (LO0)

This product enables the browsing of 2D Layout for 3D Design (LO1) data in a CATIA session, without the need for an LO1 authoring license. This capability allows users to achieve 2D and 3D visualization of 2D Layout for 3D Design data, advanced multi-sheet printing, drawing generation, product data filtering, and non-persistent measuring. LO0 is now part of basic CATIA configurations such as MD1, MD2, and HD2.

Step AP242 Support

CATIA V5-6R2013 demonstrates increased openness with the support for the latest STEP AP242, Application Protocol For Managed Model-based 3D Engineering, an automotive and aerospace standard for data exchange, visualization, and long term archiving of 3D models. In particular, it enables import and export of ISO standard BREP and Tessellated data. Driven by the aerospace and automotive industries, the recent development of STEP AP242 demonstrates the increased adoption of 3D Master in these industries. AP242 is a merge and enhancement of AP203 and AP214. This enhancement includes support for tessellated STEP AP242, providing a vendor-independent, ISO standards-based approach to exchanging compressed and tessellated data.

Multiple enhancements streamline the Class A surfacing workflow

With V5-6R2013, CATIA ICEM Shape Design Extends its high-end Class A Surface modelling capabilities, leveraging extended interoperability with ICEMSURF. The combination of ICEMSURF and CATIA ICEM provides the perfect suite of complementary tools for full Class A process coverage, from conceptualising through to final refinement and high-end detailed design. This release delivers increased productivity through user-interface enhancements and improved graphics performance. Seamless Integration with ICEMSURF increases design confidence and new blending extensions allow users to create higher quality surfaces first time around.

CATIA Configurations let you choose the right solution corresponding to your needs. They contain a predefined list of products adapted to the most frequent user profiles across industries and processes

About Dassault Systemes

As a world leader in 3D and Product Lifecycle Management (PLM) solutions, Dassault Systemes brings value to more than 130,000 customers in 80 countries. A pioneer in the 3D software market since 1981, Dassault Systemes applications provide a 3D vision of the entire lifecycle of products from conception to maintenance to recycling. The Dassault Systemes portfolio consists of CATIA for designing the virtual product - SolidWorks for 3D mechanical design - DELMIA for virtual production - SIMULIA for virtual testing - ENOVIA for global collaborative lifecycle management, EXALEAD for search-based applications and 3DVIA for online 3D lifelike experiences.
