總部位於法國波爾多Lumiscaphe，是一家專門提供互動式3D圖像綜合解決方案的公司。其核心產品Patchwork3D™能夠即時的把數模轉換為視覺化3D圖像，這是一種富有創意的設計手段。

Patchwork3D™可以直接導入常用的CAD工業模型資料檔案,通過 輕量化處理、法線檢查、貼圖映射、軸心處理、烘焙貼圖和增加材質等工藝流程,可以在很短的時間內將普通的CAD檔渲染成逼近真實的互動3D展示內容,這 種富有創意的全新設計手段,廣泛應用於航空航太、汽車製造、建築設計、消費品包裝等不同的領域, 大大縮短了設計週期與費用,有效地減少了業主與設計者的溝通時間與成本。

Patchwork3D™產品優勢

即時的動態渲染功能 Patchwork3D™改進了傳統渲染引擎的預渲染流程，在數模設計初期就可以進行即時的，高真實渲染。方便設計師在設計初期能夠觀看到產品的最終形態。

支援多種3D資料

Patchwork3D™支援多種常見的CAD檔格式來導入3D資料，它內嵌以UGS公司的Parasolid幾何引擎，可以確保有效的利用CAD數 據，從而節省了資料轉化的時間和成本。可支持：3DS(V3 V4)、OBJ、LWO(v5.5)、DXF(R12)、VRML(V1 V2)、DotXSL、STL、Parasolid(V16) 、STEP(AP203 AP214)、IGES(V4.0 V5.2 V5.3)、ProEngineer(V17至v2000i)、CATIA(v4 v5)、I-DEAS等格式。 真實尺寸的紋理和材質

Patchwork3D™可以生成極高的圖元和頂點著色效果，通過GPU計算與不同材質間的交互反應，渲染出高寫實的圖像。材質編輯器提供各種類比真實物理質感的材質與尺寸標注，因此可以模擬出與真實物品一比一的高寫實質感。

高寫實的數字樣機

Patchwork3D™的光照引擎採用獨特的圖形演算法,通過硬體加速技術提前預覽烘焙後的光影效果即時的各式燈光調整，展生高寫實的3D即時渲染展示，獲取真實的視覺體驗。 變革產品設計流程

Patchwork3D™幫助用戶通過3D互動式的圖像來驗證產品的結構和比例。還可以創建無限數量不同型號，材料和色彩的虛擬原型來加速產品設計流程。

簡化專案審核流程

在創建物理原型前便可以對產品模型的有效性進行評估和驗證，在項目審查的過程中可以隨時對產品的設計方向進行修正，以適應當前的市場定位。

溝通從產品設計開始

Patchwork3D™在幾分鐘內便可以製作出產品模型的視頻和圖片，溝通和展示設計者的每一步設計意圖。沉浸式的真實體驗

高級視覺化功能支援與頭部跟蹤系統和立體顯示設備相結合，可以獲取產品1:1等比例真實的沉浸式體驗。

Global solution for the creation of 3D images from 3D databases in their native format. Patchwork 3D allows to modify your product designs in real-time with realistic results, enabling easy design reviews and marketing decisions.

Patchwork3D is an intuitive creation process for interactive 3D images. Patchwork3D CAD edition imports your models from a large variety of formats. It embeds the Parasolid geometric engine grom UGS Corp. in order to ensure the best exploitation possible of your CAD data. The real-time interactive 3D rendering of Patchwork3D includes an illumination model made from spherical environments in high dynamic for an optimal quality of images and an intuitive setting of the materials. Patchwork3D's materials simulate real textures and their interaction with light to obtain a striking realism. The very quick computation of very high-definition images and animations enables, with traditionnal communication tools, a direct integration of your graphic elements.

The two modules of Patchwork3D increase your productivity by separating on one hand the import and optimisation of CAD models, nad on the other hand the work on the mapping and presentation of the products. Patchwork3D uses the maximum power of the latest generation of graphic cards as to ensure an interactive display that enjoys smooth fluidity and striking realism. Uses the most common CAD formats to import your 3D data and avoid intermediate stages of file conversion. Accessible by all the services that are involved in marketing, communication, sales and design, Patchwork3D uses the 3D models directly to develop interactive presentations of high visual quality. Patchwork3D enters the digital process very easily and provides a series of easy to use tools so as to make movies and interactive images of very high definition.

About Lumiscaphe

Since 2001 our teams have been inventing innovative hybrid solutions capable of providing answers to specific problems in fields related to 3D imaging.

We now have sound expertise in the design of innovative products in the field of digital aspect mockups and real-time photorealistic 3D rendering.
